Northern Connectors Harting DIN 41 612 Connectors - Manual (Page 212)

30
.
16
09 99 000 0620
09 99 000 0621
09 99 000 0622
09 99 000 0623
09 99 000 0629
09 99 000 0075
09 99 000 0076
09 99 000 0077
09 99 000 0640
09 99 000 0641
09 99 000 0642
09 99 000 0630
09 99 000 0631
09 99 000 0632
BC / har-bus ® 64
FC
09 99 000 0191
BC / FC 1 / har-bus ® 64
FC 2
FC 3
BC / FC 1 / har-bus ® 64
FC 2
FC 3
To
ol
in
g
BC: 0.09 - 0.50 mm²
FC 1: 0.09 - 0.25 mm²
FC 2: 0.14 - 0.56 mm²
FC 3: 0.50 - 1.50 mm²
BC: 0.13 mm² (solid wire)
BC: 0.09 - 0.50 mm²
FC 1: 0.09 - 0.25 mm²
FC 2: 0.14 - 0.56 mm²
FC 3: 0.50 - 1.50 mm²
Wire gauge
Wire gauge
Crimping tools
Identification Part No. Drawing Dimensions in mm
HARTING
crimping tool
for individual contacts
BC / FC and har-bus ® 64
HARTING
crimping tool
for individual contacts
Crimping insert set
for individual contacts
each set contains
locator and crimp insert
top and bottom part
Locator
Service case
for crimping tool and
5 sets inserts,
incl. screwdriver
for insert change,
without contents
Insertion and removal see page 03.10
Order crimping inserts separately
Wire gauge
FC 1: 0.14 - 0.25 mm²
FC 2: 0.25 - 0.56 mm²
FC 3: 0.75 - 1.50 mm²
Locator is supplied with the tool.
Crimping tool
for individual contacts
FC 1, FC 2 and FC 3
(Service tool)
BC / FC 1 / har-bus ® 64
FC 2
FC 3
BC / har-bus ® 64
solid wire
Locator
