Northern Connectors Harting DIN 41 612 Connectors - Manual (Page 101)

02
.
11
ha
r-
bu
s 6
4
160 z, a, b, c, d 02 01 160 2101
02 01 160 1101
02 01 160 1105 2)
160 z, a, b, c, d 02 01 160 2102
02 01 160 1102
02 01 160 1106 2)
Number Contact
Part No. Performance levels according to IEC 61 076-4-113
Identification of contacts arrangement
Explanation chapter 00
2 1
Male connectors, angled, SMC compatible
Number of contacts
160
Dimensions in mm
Male connector*
without retention clip
with retention clip
Dimensions
* Pre-leading contacts at positions d1, d2, d31 and d32
1) Recommendation for variants with clip: Drillings can be enlarged up to 3.1 mm ø to reduce standard mounting force (see chapter 00)
2) Special variant with min. 1.27 µm (50 µinch) Au and SnPb on termination
Board drillings
Mounting side
row
position
all holes
Cross section of
solder terminations
Row z:
A = 0.21 - 0.25 mm²
Rows a, b, c:
A = 0.25 - 0.33 mm²
Row d:
A = 0.29 - 0.32 mm²
A = cross area of contacts
· IEC 61 076 - 4 - 113
row
position
mounting hole
centre line
with clip without clip
