Northern Connectors Harting DIN 41 612 Connectors - Manual (Page 113)

03
.
13
32
09 04 232 6826 09 04 232 2826
09 04 232 6826 222 f)
09 06 000 9912 1)
DIN
P
ow
er
up t
o 6 A
DIN 41 612 · Type D
Female connectors
Number of contacts
32
Number Contact
Identification of contacts arrangement
Part No . Performance levels according to IEC 60603-2 . Explanation chapter 00
2 1
Female connector
with angled
solder pins
1 x 1 mm
Dimensions
Fixing bracket
Metal
1) order 2 pieces
for one connector
Board drillings
Mounting side
Dimensions in mm
all holes
f) Railway classification NFF 16-101, Smoke index: F1, Flammability class: I2
