30
.
07
09 99 000 0198
09 99 000 0200
09 99 000 0239
To
ol
in
g
Repair tooling
· Instructions page 30.08
Identification for use with Part No. Drawing Dimensions in mm
Male
connectors
Type Q, 2Q,
3Q
R, 2R,
3R
Removal tool
for moulding
Insertion tool
for single male
press-in contacts
Removal tool
for single male
contacts
Termination
length
17 mm 09 99 000 0197
Press-out tool
11.5 mm 09 99 000 0221
13 - 13.2 mm 09 99 000 0219
4.5 - 5.3 mm 09 99 000 0220
Male
connectors 09 99 000 0240
Type Q, 2Q, 3Q
R, 2R, 3R
Female
connectors
Type B, 2B, 3B
C, 2C, 3C
Female
connectors 09 99 000 0241
Type F
Termination support
for protection
against bending
of 13 mm - 17 mm
terminations
Male
connectors 09 99 000 0218
Type Q, 2Q, 3Q
R, 2R, 3R
SEK 18*
Female
connectors
Type B, 2B, 3B
C, 2C, 3C
F
Support block
for repair and removal
* Connectors see separate catalogue
Termination length [mm] x [mm] y [mm]
17 12 18.7
13 - 13.2 12 22.7
11.5 14 20.1
4.5 - 5.3 12 30.2
With the different dimension y no adjustment of hand
bench press necessary.
