Northern Connectors Harting DIN 41 612 Connectors - Manual (Page 71)

01
.
45
Y
a
b
DIN
S
ig
na
l
up t
o 2 A
DIN 41 612 · complementary type M invers
Male connectors
Number of contacts
78+2, 60+4,
42+6, 24+8
Dimensions
Board drillings
Mounting side
Identification Drawing Dimensions in mm
Board drillings depend on type and special contact loading
a b
2.5
ø 0.7 Solder pins 4.0
6.0
13 l 0.6 Wrap posts
5.0 –
Press-in pins
13 –
Y
Solder 1 ± 0.1
Press-in
see recommendation
page 00.25
Order high current,
high voltage, coaxial
and fibre optic contacts
separately, see pages
01.38 ff
