News in this Catalogue
DIN 41 612 type 3C Crimp
Nowadays, many PCBs are smaller than the standard size
3HE. HARTING offers a new crimp connector with housing
in order to assemble cables that require less space.
The well-known and reliable BC crimp contacts are used
for this product.
For further details see pages 01.34 and 20.08.
DIN 41 612 type 3Q / 3R –
Even smaller, and just as rugged
The density of the electronics on PCBs is constantly
increasing, while the PCBs and components are getting
smaller and smaller. This trend also results in a need for
smaller and smaller connectors.
The new type 3Q and 3R male connectors are available
both with and without flange, enabling further space
reductions. The connectors come in solder, SMC (Surface
Mount Compatible) or press-in technology and are
especially suitable for mezzanine applications.
For further details see pages 01.54 and 01.58.
DIN 41 612 Female connector H 15
with press-in pins
Type H15 is used successfully as power connector for
many years. Now, HARTING offers a female connector
type H15 with press-in pins. Press-in is already our fourth
termination technology for female connector type H15
besides cage clamp, solder and faston.
The new portfolio includes two versions with 2.54 mm and
5.08 mm contact pitch on the termination side.
For further details see page 04.15.
Fixing brackets for full metal housings D20
The new metallized fixing brackets give a robust
mechanical connection with reliable screws and
additionally through our new screwless locking solution.
Moreover a good electrical connection is guaranteed
between the full metal housings D20, the fixing brackets
and the rack systems.
The locking levers simplify the handling notably and can
also be used for daughter cards mounting and removal.
For further details see page 20.32.
DIN 41 612 type 3C Crimp
DIN 41 612 types 3Q / 3R DIN 41 612 female connector H15 press-in
Fixing brackets
