DIN 41 612 · Type C
Male connectors
Number of contacts
96, 64, 32
Number Contact
Identification of contacts arrangement
Part No. Performance levels according to IEC 60603-2. Explanation chapter 00
3 2 1
Male connector
with angled
solder pins
Male connector
with straight
solder pins
▲ Male connectors with 2 leading contacts [(0.8 mm) pos. a1 and
a32]. Lagging pins on request.
b) Connectors with snap-in clips see chapter 00
c) Connectors with coding see chapter 00
d) CTI > 400
f) Railway classification NFF 16-101, Smoke index: F1,
Flammability class: I2
