Northern Connectors Harting DIN 41 612 Connectors - Manual (Page 131)

03
.
31
1 09 06 000 6484 09 06 000 6474
2 09 06 000 6481 09 06 000 6471
3 09 06 000 6482 09 06 000 6472
1 09 06 000 7484 09 06 000 7474
2 09 06 000 7481 09 06 000 7471
3 09 06 000 7482 09 06 000 7472
1 09 06 000 8484 09 06 000 8474
2 09 06 000 8481 09 06 000 8471
3 09 06 000 8482 09 06 000 8472
09 06 000 6420
48
09 06 248 3201
09 06 248 3201 222 f)
FC 1
FC 2
FC 3
DIN
P
ow
er
up t
o 6 A
DIN 41 612 · Type F
Female connectors
Number of contacts
max . 48
Number
Identification of contacts Part No . Drawing Dimensions in mm
Female connector
for crimp contacts 1)
Order contacts separately
Contact arrangement View from termination side
Shell housing see chapter 20
1) With shroud coding, see also chapter 00
Female crimp FC
contacts
Bandoliered contacts
(approx . 2 ,500 pieces)
Bandoliered contacts
(approx . 250 pieces)
Individual contacts 2)
Wire gauge Insulation ø
mm² AWG mm
Identification
Identification Wire gauge
Part No . Performance levels according to IEC 60603-2 . Explanation chapter 00
2 1
Identification
Bandoliered
contacts
Individual contacts
Female contacts with
solder lugs 3)
(lockable)
2) Packaging unit 1,000 pieces
3) Solder contacts must not be used together with shell housing A . Special contact surface: 2 µm gold .
f) Railway classification NFF 16-101, Smoke index: F1, Flammability class: I2
3 .5 + 0 .5 mm of insulation is stripped from the wires
to be crimped
For the fabrication in line with the specification please
use exclusively crimp tools approved by HARTING
(see DIN EN 60 352-2)
Insertion, removal and crimping tools see chapter 30
1 0 .09 - 0 .25 28 - 24 0 .7 - 1 .5
2 0 .14 - 0 .56 26 - 20 0 .8 - 2 .0
3 0 .5 - 1 .5 20 - 16 1 .6 - 2 .8
