Housing parts supplied
Cable access
Fitting female connectors
Separate accessories
for housings
Shell housing A for type F
1c Shell 1x
2c Cover 1x
4 Cable clamp 2x
5 Screw
BZ 2 .9 x 9 .5
DIN ISO 1481 4x
6 Hexagonal nut M3
DIN EN ISO 4032 4x
7 Screw
M3 x 12
DIN EN ISO 1207 4x
Moulding material: thermoplastic resin, glass-fibre filled, UL 94-V0
1a Casing shell 2x
3 Blinding piece 1x
4 Cable clamp 1x
5 Screw
BZ 2 .9 x 9 .5
DIN ISO 1481 1x
6 Hexagonal nut M3
DIN EN ISO 4032 2x
7 Screw
M3 x 12
DIN EN ISO 1207 2x
