Northern Connectors Harting DIN 41 612 Connectors - Manual (Page 196)

20
.
34
09 06 001 9904
09 06 001 9902
09 06 001 9903
II
I
I
II
Sh
ell
hou
si
ng
s
Retaining frames
Identification Part No. Drawing Dimensions in mm
Retaining frame
without contact
elements
Retaining frame with
2 contact pins and
ground termination
Retaining frame with
2 contact sockets and
ground termination
Mounting example Connectors in the retaining frame with contact sockets
Guide pin
Ground
termination
M 2.5 x 6
DIN EN ISO
1207
Contact socket
Guide sockets
Each retaining frame is supplied with 4 fixing screws for mounting the inserts
and with 2 guide pins and sockets that provide mechanical protection for
the contacts during mating and disconnection. These can also be used as a
coding system to prevent cross plugging of adjacent connectors.
