Shell housing D 15 for types F, H and MH
Mechanical guiding and first mating g
round connection
Loc
king scre
ws 2 x
Type F f
emale connector
Type H f
emale connector
Type MH f
emale connector
Type F interf
ace connector I
Crimp ter
minal
Solder ter
minal
Faston
Cage clamp
Crimp ter
minal
Crimp ter
minal
Housing parts supplied
Fitting male connectors
Fitting female connectors
Separate accessories
for housings
1 Casing shell 2x
2 Blinding plate 1x
3 Cable tie 2x
4 Blinding piece 2x
5 Hexagonal nut M2.5
DIN EN ISO 4035 2x
6 Screw BZ 2.9 x 9.5
DIN ISO 1481 2x
7 Screw M2.5 x 12
DIN EN ISO 7045 2x
Moulding material: thermoplastic resin,
glass-fibre filled, UL 94-V0
