48 09 05 048 6924 f)
DIN
P
ow
er
up t
o 6 A
DIN 41 612 · complementary to type E
Interface connector I
Number of contacts
48
Number
Identification of contacts Part No . Drawing Dimensions in mm
Performance level 2
acc . to IEC 60 603-2
Interface connector I
with solder pins
0 .6 x 0 .6 mm
Panel cut out
Board drillings
Mounting side
Contact arrangement View from termination side
f) Railway classification NFF 16-101, Smoke index: F1, Flammability class: I2
M 2 .5 DIN EN
ISO 4 032
