Northern Connectors Harting DIN 41 612 Connectors - Manual (Page 181)

20
.
19
09 06 000 9957
09 06 000 9968
09 06 000 9930 1)
09 06 000 9911 1)
I II
III IV
I
A B C
III
IV
09 06 001 9939
II
C
A B C
Sh
ell
hou
si
ng
s
Railway classification NFF 16-101, Smoke index: F1, Flammability class: I2
Open hood G
for types E, F, H
and MH, for applications
Supplied with:
Open hood 1x
Locking screw 2x
(09 06 000 9958)
Cable tie 1x
Screw 2x
Open hood G
for types E, F, H
and MH, for application
Supplied with:
Open hood 1x
Pre-assembled,
undetachable locking
screw 2x
Cable tie 1x
Screw 2x
Open hood G, junction element O, locking lever
Identification Part No. Drawing Dimensions in mm
Junction element O
for type F
Locking lever
for type F, H and MH
Female connector
U element
I element
Fixing
brackets B
Female connector
Male connector
2 x M 2.5 x 20
DIN EN ISO 7045
Cable tie 1 x
M 2.5 x 8
DIN EN ISO 1207 2)
M 2.5 DIN EN ISO 4 032 2)
M 2.5 DIN EN ISO 4 032 2)
M 2.5 x 8
DIN EN ISO 1207 2)
1) Order 2 pieces
for one female connector
Female connector
Female connector type F
Supplied with:
Junction element 2x
Cable tie 2x
Screw 2x
Screw M2.5 x 20 2x
2) nut and screw
not supplied
with locking
levers
2 x ST 2.2 x 9.5 F-Z;
E1U;
ISO 7049
2 x ST 2.2 x 9.5 F-Z;
E1U;
ISO 7049
