Northern Connectors Harting DIN 41 612 Connectors - Manual (Page 213)

30
.
17
09 99 000 0246
09 99 000 0249
09 99 000 0250
09 99 000 0251
09 99 000 0628
09 99 000 0158
09 99 000 0252
09 99 000 0248
09 99 000 0247
09 99 000 0119
09 99 000 0120
09 99 000 0627
09 99 000 0101
09 99 000 0087
09 99 000 0100
09 99 000 0088
To
ol
in
g
Crimping tools
Identification Part No. Drawing Dimensions in mm
Main drive,
foot-operated
115/230 V – 50 Hz
HARTING
semi-automatic
crimping device
Real holder
for 2,500 contacts
FC 1, FC 2 or FC 3
and
for 5,000 contacts
BC / har-bus ® 64
Locator not necessary
Wire gauge
0.09 - 0.5 mm²
Crimping head for
bandoliered contacts
BC / har-bus ® 64
0.09 - 0.25 mm²
0.14 - 0.56 mm²
0.5 - 1.5 mm²
0.13 mm² (solid wire)
FC 1
FC 2
FC 3
BC/har-bus ® 64
solid wire
Wire gauge
0.09 - 0.5 mm²
HARTING crimping tool
for bandoliered
contacts (500 pieces)
BC / har-bus ® 64
Wire gauge
0.09 - 0.25 mm²
0.14 - 0.56 mm²
0.50 - 1.50 mm²
0.13 mm² (solid wire)
for bandoliered
contacts (250 pieces)
FC 1
FC 2
FC 3
BC / har-bus ® 64 solid wire
for contacts BC / har-bus ® 64
for contacts
FC 1, FC 2 and FC 3
Removal tool
for contacts BC / har-bus ® 64
for contacts
FC 1, FC 2 and FC 3
Insertion tool
