09 05 148 7921 09 05 148 6921 09 05 148 2921
09 05 148 6921 222 f) 09 05 148 2921 222 f)
48 09 05 348 6921 b)
09 05 648 6921 c) 09 05 648 2921 c)
09 05 848 6921 b)c)
46 + 2 ▲ 09 05 148 6951
09 05 148 7931 09 05 148 6931 09 05 148 2931
48 09 05 348 6931 b)
09 05 648 6931 c)
48
09 05 148 6920 d)
09 05 348 6920 b)d)
46 + 2 ▲ 09 05 148 6961
I II
I
II
I
II
I
II
SMC
DIN
P
ow
er
up t
o 6 A
DIN 41 612 · Type E
Male connectors
Number of contacts
48
Number Contact
Identification of contacts arrangement
Part No . Performance levels according to IEC 60603-2 . Explanation chapter 00
3 2 1
Row separation
termination side 5 .08 mm
Row separation
termination side 2 .54 mm
Male connector
with angled
solder pins
Dimensions
Board drillings
Mounting side
Angled
solder pins
▲ Male connectors with 2 leading contacts [(0 .8 mm) pos . a2 and a32]
Other contact arrangements on request
b) Connectors with snap-in clips see chapter 00
c) Connectors with coding see chapter 00
Dimensions in mm
d) CTI > 400
f) Railway classification NFF 16-101, Smoke index: F1,
Flammability class: I2
