Technical data
Rated data
Operation at 400 V
3.3
3.3.1
l
3.3−1
EDSVS9332S EN 6.0−07/2013
3.3
Rated data
)
Note!
The controllers EVS9324, EVS9326 and EVS9328
EVS9332 may
only be operated with the prescribed mains chokes and mains
filters.
3.3.1
Operation at 400 V
Basis of the data
Voltage
Frequency
AC mains connection
[V
rate
d
]
3/PE AC 320 V − 0 % ... 440 V + 0 %
45 Hz − 0 % ... 65 Hz + 0 %
DC−mains connection
(alternatively)
[U
DC
]
DC 450 V − 0 % ... 620 V + 0 %
˘
Output voltage
With mains choke
3 ~ 0 approx. 94 % V
rated
˘
Without mains choke
3 ~ 0 ... U
N
˘
9300
Mains current
1)
Typical motor power
Output power
Power loss
With
mains choke
Without
mains choke
ASM
(4−pole)
8 kHz
2)
U, V, W
+U
G
, −U
G
3)
Type
I
r
[A]
I
r
[A]
P
r
[kW]
P
r
[hp]
S
r8
[kVA]
P
DC
[kW]
P
V
[W]
EVS9321−xS
1.5
2.1
0.37
0.5
1.0
2.0
100
EVS9322−xS
2.5
3.5
0.75
1.0
1.7
0.75
110
EVS9323−xS
3.9
5.5
1.5
2.0
2.7
2.2
140
EVS9324−xS
7.0
˘
3.0
4.0
4.8
0.75
200
EVS9325−xS
12.0
16.8
5.5
7.5
9.0
0
260
EVS9326−xS
20.5
˘
11.0
15.0
16.3
0
390
EVS9327−xS
27.0
43.5
15.0
20.0
22.2
10
430
EVS9328−xS
44.0
˘
22.0
30.0
32.6
4
640
EVS9329−xS
53.0
˘
30.0
40.0
40.9
0
810
EVS9330−xS
78.0
˘
45.0
60.0
61.6
5
1100
EVS9331−xS
100
˘
55.0
75.0
76.2
0
1470
EVS9332−xS
135
˘
75.0
100
100.5
0
1960
Bold print = Lenze setting
1)
Mains currents at 8 kHz switching frequency
2)
Switching frequency of the inverter
3)
Power which can additionally be drawn from the DC bus at operation with power−adapted motor
