Lenze EVS9332xS - Manual (Page 280)

Configuration
Code table
8
8.4
l
8.4−39 EDSVS9332S EN 6.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0896
s
N2−LIM 1000 FIXED0% ® Selection list 1 MCTRL
Configuration of input signal for 2. speed
limitation value
C0897
s
PHI−ON 1000 FIXED0 ® Selection list 2 MCTRL
Configuration of switch−on signal for angle
controller
C0898
s
FLD−WEAK 1006 FIXED100% ® Selection list 1 MCTRL
Configuration of input signal for field
weakening
C0899
s
N/M−SWT 1000 FIXED0 ® Selection list 2 MCTRL
Configuration of input signal for change−over
between n and M control
C0900
s
QSP 10250 R/L/Q−QSP ® Selection list 2 MCTRL
Configuration of control signal for activation
C0901
s
I−SET 1000 FIXED0% ® Selection list 1 MCTRL
Configuration of input signal for loading the I
component for the speed controller
C0902
s
I−LOAD 1000 FIXED0 ® Selection list 2 MCTRL
Configuration of tripping signal for loading
the I component for the speed controller
C0903
s
P−ADAPT 1006 FIXED0% ® Selection list 1 MCTRL
Configuration of input signal for adaptation
of the angle controller
C0906 g −199.99 {0.01 %} 199.99 MCTRL
Display of analog input signals
1 (C0890)
2 (C0891)
3 (C0892)
4 (C0893)
5 (C0895)
6 (C0896)
7 (C0898)
8 (C0901)
9 (C0903)
C0907
g MCTRL
Display of digital input signals
1 (C0897)
2 (C0899)
3 (C0900)
4 (C0902)
C0908 (C0894) g −2147483647 {1 inc} 2147483647 Set phase signal
l 1 rev. = 65536 inc
C0909 SPEED LIMIT 1 1
2
3 +/− 175 %
0 ... +175 %
−175 ... 0 % Limitation of direction of rotation for the
speed setpoint
C0920
s
REF−ON 1000 FIXED0 ® Selection list 2 REF
Configuraton of digital input signal
Activation of homing function
C0921
s
REF−MARK 1000 FIXED0 ® Selection list 2 REF
Configuraton of digital input signal
Digital reference switch
C0922
s
REF−PHI−IN 1000 FIXED0INC ® Selection list 3 REF
Configuration of angle input signal
C0923
s
REF−N−IN 1000 FIXED0% ® Selection list 1 REF
Configuration of speed input signal
