Configuration, Code table – Lenze EVS9332xS User Manual
Page 255

Configuration
Code table
8.4
l
8.4−14
EDSVS9332S EN 6.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C0336 ACT VP
g 0.0
{0.1}
500.0 PCTRL
Current V
p
C0337 BI/UNIPOLAR
0
0
1
Bipolar
Unipolar
PCTRL
Bipolar/unipolar range
C0338 ARIT1 FUNCT
1
0
1
2
3
4
5
OUT = IN1
OUT = IN1 + IN2
OUT = IN1 − IN2
OUT = IN1 × IN2
OUT = IN1 / IN2
OUT = IN1/(100% − IN2)
ARIT1
Function selection
C0339
s
® Selection list 1 ARIT1
Configuration − analog input signals
1 ARIT1−IN1
1000 FIXED0%
2 ARIT1−IN2
1000 FIXED0%
C0340
g
ARIT1
Display of analog input signals
1 (C0339/1)
2 (C0339/2)
C0350 CAN ADDRESS
1
1
{1}
63 CAN
System bus node address
l
Change becomes effective after ˜reset
node˜ command
C0351 CAN BAUD
RATE
0
0
1
2
3
4
500 kbps
250 kbps
125 kbps
50 kbps
1000 kbits/s
CAN
System bus baud rate
l
Change becomes effective after ˜reset
node˜ command
C0352 CAN MST
0
0
1
Slave
Master
CAN
Configuration of system bus nodes
l
Change becomes effective after ˜reset
node˜ command
C0353
0
1
C0350
C0354
CAN
CAN−IN / CAN−OUT selection of the system
bus address
1 IN/OUT1 ADR
0
CAN−IN1, CAN−OUT1
2 IN/OUT2 ADR
0
CAN−IN2, CAN−OUT2
3 IN/OUT3 ADR
0
CAN−IN3, CAN−OUT3
C0354
1
{1}
513 CAN
CAN−IN / CAN−OUT node address 2
l
Individual addressing of the system bus
process data objects
1 IN1 ADR2
1
CAN−IN1
2 OUT2 ADR2
129
CAN−OUT1
3 IN2 ADR2
257
CAN−IN2
4 OUT2 ADR2
258
CAN−OUT2
5 IN3 ADR2
385
CAN−IN3
6 OUT3 ADR2
386
CAN−OUT3
C0355
g 0
{1}
2047 CAN
System bus identifiers
1 IN1 ID
2 OUT1 ID
3 IN2 ID
4 OUT2 ID
5 IN3 ID
6 OUT3 ID
