Configuration
Code table
8
8.4
l
8.4−38 EDSVS9332S EN 6.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0870
s
® Selection list 2 DCTRL
Configuration of digital input signals (inhibit
controller)
1 CINH1 1000 FIXED0
2 CINH2 1000 FIXED0
C0871
s
TRIP−SET 54 DIGIN4 ® Selection list 2 DCTRL
Configuraton of digital input signal
C0876
s
TRIP−RES 55 DIGIN5 ® Selection list 2 DCTRL
Configuraton of digital input signal
C0878
g DCTRL
Display of digital input signals
1 (C0870/1)
2 (C0870/2)
3 (C0871)
4 (C0876)
C0879 0
1 No reset
Reset DCTRL
Reset control words
1 RESET C135 0
2 RESET AIF 0
3 RESET CAN 0
C0880 ® Selection list 2 DCTRL
Configuration of digital input signals
1 PAR*1 1000 FIXED0
2 PAR*2 1000 FIXED0
C0881 PAR−LOAD 1000 FIXED0 ® Selection list 2 DCTRL
Configuraton of digital input signal
C0884 g DCTRL
Display of digital input signals
1 PAR*1
2 PAR*2
3 PAR−LOAD
C0885
s
R 51 DIGIN1 ® Selection list 2 R/L/Q
Configuraton of digital input signal(CW
rotation)
C0886
s
L 52 DIGIN2 ® Selection list 2 R/L/Q
Configuraton of digital input signal(CCW
rotation)
C0889 g R/L/Q
Display of digital input signals
1 (C0885)
2 (C0886)
C0890
s
N−SET 5050 NSET−NOUT ® Selection list 1 MCTRL
Configuration of input signal for speed
setpoint
C0891
s
M−ADD 1000 FIXED0% ® Selection list 1 MCTRL
Configuration of input signal for torque
setpoint
C0892
s
LO−M−LIM 5700 ANEG1−OUT ® Selection list 1 MCTRL
Configuration of input signal for lower torque
limit
C0893
s
HI−M−LIM 19523 FCODE−472/3 ® Selection list 1 MCTRL
Configuration of input signal for upper
torque limit
C0894
s
PHI−SET 1000 FIXED0INC ® Selection list 3 MCTRL
Configuration of input signal for rotor
position setpoint
C0895
s
PHI−LIM 1006 FIXED100% ® Selection list 1 MCTRL
Configuration of input signal for angle
controller limit
