Configuration
Code table
8.4
l
8.4−27
EDSVS9332S EN 6.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C0680 FUNCTION
6
1
2
3
4
5
6
IN1 = IN 2
IN 1 > IN2
IN 1 < IN2
|IN1| = |IN2|
|IN1| > |IN2|
|IN1| < |IN2|
CMP1
Selection of the function on how the inputs
IN1 and IN2 are to be compared
C0681 HYSTERESIS
1.00
0.00
{0.01 %}
100.00 CMP1
Hysteresis
C0682 WINDOW
1.00
0.00
{0.01 %}
100.00 CMP1
Window
C0683
s
® Selection list 1 CMP1
Configuration − analog input signals
1 CMP1−IN1
5001 MCTRL−NACT
2 CMP1−IN2
19500 FCODE−17
C0684
g −199.99
{0.01 %}
199.99 CMP1
Display of analog input signals
1 (C0683/1)
2 (C0683/1)
C0685 FUNCTION
1
1
2
3
4
5
6
IN1 = IN2
IN 1 > IN2
IN 1 < IN2
|IN1| = |IN2|
|IN1| > |IN2|
|IN1| < |IN2|
CMP2
Selection of the function on how the inputs
IN1 and IN2 are to be compared
C0686 HYSTERESIS
1.00
0.00
{0.01 %}
100.00 CMP2
Hysteresis
C0687 WINDOW
1.00
0.00
{0.01 %}
100.00 CMP2
Window
C0688
s
® Selection list 1 CMP2
Configuration − analog input signals
1 CMP2−IN1
1000 FIXED0%
2 CMP2−IN2
1000 FIXED0%
C0689
g −199.99
{0.01 %}
199.99 CMP2
Display of analog input signals
1 (C0688/1)
2 (C0688/2)
C0690 FUNCTION
1
1
2
3
4
5
6
IN1 = IN 2
IN 1 > IN2
IN 1 < IN2
|IN1| = |IN2|
|IN1| > |IN2|
|IN1| < |IN2|
CMP3
Selection of the function on how the inputs
IN1 and IN2 are to be compared
C0691 HYSTERESIS
1.00
0.00
{0.01 %}
100.00 CMP3
Hysteresis
C0692 WINDOW
1.00
0.00
{0.01 %}
100.00 CMP3
Window
C0693
s
® Selection list 1 CMP3
Configuration − analog input signals
1 CMP3−IN1
1000 FIXED0%
2 CMP3−IN2
1000 FIXED0%
C0694
g −199.99
{0.01 %}
199.99 CMP3
Display of analog input signals
1 (C0693/1)
2 (C0693/2)
C0695 FUNCTION
2
1
2
IN 1 < IN2
|IN1| < |IN2|
PHCMP1
Selection of the function on how the inputs
IN1 and IN2 are to be compared
