Configuration
Code table
8.4
l
8.4−25
EDSVS9332S EN 6.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C0594 MONIT SD6
®
0
2
3
Trip
Warning
Off
SD6monitoring
Configuration of "motor temperature sensor"
monitoring
à
Depending on C0086
C0595 MONIT CE4
3
0
2
3
Trip
Warning
Off
CE4monitoring
Configuration of "CAN bus off" monitoring
C0596 NMAX LIMIT
5500 0
{1 rpm}
16000 System speed monitoring
C0597 MONIT LP1
3
0
2
3
Trip
Warning
Off
LP1monitoring
Configuration of motor phase failure
monitoring
C0598 MONIT SD5
3
0
2
3
Trip
Warning
Off
SD5monitoring
Configuration monitoring master current at
X5/1.2 < 2mA
C0599 LIMIT LP 1
5.0
1.0
{0.1 %}
10.0 LP1monitoring
Current limit value for motor phase
monitoring
C0600 FUNCTION
1
0
1
2
3
4
5
OUT = IN1
OUT = IN1 + IN2
OUT = IN1 − IN2
OUT = IN1 × IN2
OUT = IN1 / IN2
OUT = IN1/(100% − IN2)
ARIT2
Function selection
C0601
s
IN
® Selection list 1 ARIT2
Configuration − analog input signals
1
1000 FIXED0%
ARIT2−IN1
2
1000 FIXED0%
ARIT2−IN2
C0602
g −199.99
{0.01 %}
199.99 ARIT2
Display of analog input signals
1 (C0601/1)
2 (C0601/2)
C0606 MONIT OC8
2
0
2
3
Trip
Warning
Off
Configuration of the I
2
× t advance warning
The threshold is set in C0127.
C0610
s
IN
® Selection list
1
ADD
Configuration − analog input signals
1
1000 FIXED0%
ADD1−IN1
2
1000 FIXED0%
ADD1−IN2
3
1000 FIXED0%
ADD1−IN3
C0611
g −199.99
{0.01 %}
199.99 ADD
Display of analog input signals
1 (C0610/1)
2 (C0610/2)
3 (C0610/3)
C0620 DB1 GAIN
1.00
−10.00
{0.01}
10.00 DB1 gain
Gain of dead band component DB1
C0621 DB1 VALUE
1.00
0.00
{0.01 %}
100.00 DB1 dead band
Dead band of DB1
C0622
s
DB1−IN
1000 FIXED0%
® Selection list 1 DB1
Configuration of analog input signal
C0623 (C0622)
g −199.99
{0.01 %}
199.99 DB1
Display of analog input signal
C0630 MAX LIMIT
100.0
0
−199.99
{0.01 %}
199.99 LIM upper limit
Upper limit of limiter LIM1
C0631 MIN LIMIT
−100.0 −199.99
{0.01 %}
199.99 LIM lower limit
Lower limit of limiter LIM1
