Configuration
Code table
8.4
l
8.4−49
EDSVS9332S EN 6.0−07/2013
IMPORTANT
Possible settings
Code
Selection
Lenze
Designation
No.
C1245
g −199.99
{0.01 %}
1999.99 CONVPHPH1
Display of analog input signals
1 (C1240/1)
2 (C1240/2)
C1246 (C1241)
g
CONVPHPH1
Display of digital input signal
C1247 (C1242)
g −2147483647
2147483647 CONVPHPH1
Input signal display
C1250
s
IN
1000 FIXEDPHI−0
® Selection list 4 CONVPP1
Input signal configuration
C1251
s
1000
® Selection list 3 CONVPP1
Input signal configuration
1 CONVPP1−NU
M
FIXED0INC
2 CONVPP1−DEN
FIXED0INC
C1253 (C1250)
g −32767
{1 rpm}
32767 CONVPP1
Input signal display
C1254
g −2147483647
{1}
2147483647 CONVPP1
Display of input signals
1 CONVPP1−NU
M
2 CONVPP1−DEN
C1255
s
N−TRIM2
1000 FIXEDPHI−0
® Selection list 4 DFSET
Input signal configuration
C1258 (C1255)
g −32767
{1 rpm}
32767
C1260 OFFSET
0
−16383
{1}
16383 GEARCOMP
Offset
C1261 NUM
1
−32767
{1}
32767 GEARCOMP
Numerator
C1262 DENUM
1
1
{1}
32767 GEARCOMP
Denominator
C1265
s
TORQUE
1000 FIXED0%
® Selection list 1 GEARCOMP
Configuration of input signal correction
C1266
s
PHI−IN
1000 FIXED0INC
® Selection list 3 GEARCOMP
Input signal configuration
C1268 (C1265)
g −199.99
{0.01 %}
199.99 GEARCOMP
Display of analog input signal
C1269 (C1266)
g −2147483647
{1}
2147483647 GEARCOMP
Input signal display
C1270
s
® Selection list 3 PHCMP3
Input signal configuration
1 PHCMP3−IN1
1000 FIXED0INC
2 PHCMP3−IN2
1000 FIXED0INC
C1271
g −2147483647
{1}
2147483647 PHCMP3
Display of input signals
1 (C1270/1)
2 (C1270/2)
C1272 FUNCTION
2
1
2
IN1 < IN2
|IN1| < |IN2|
PHCMP3
Selection of the comparison operation
C1290 MONIT P16
3
0
2
3
Trip
Warning
Off
P16 monitoring
Configuration of monitoring in the case of a
sync error
C1292 MONIT P19
2
0
Trip
P19monitoring
Configuration of monitoring a limitation of
the input value at DFIN
2
Warning
3
Off
