Configuration
Code table
8
8.4
l
8.4−9 EDSVS9332S EN 6.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0141 FCODE
(SETVAL)
0.0 −199.9 {0.1 %} 199.9 Main setpoint
C0142 START
OPTIONS
1 Start option
0 Start lock l Automatic start inhibited after
– Mains connection
– Reset of a message (t > 0.5 s)
– TRIP RESET
l Start after HIGH−LOW−HIGH level change
at X5/28
1 Auto start Automatic start if X5/28 = HIGH
C0150 STATUS WORD g 0 {1} 65535 Status word when linked to automation
interfaces
l Binary interpretation indicates the bit
states
C0151 FDO (DW) g Hexadecimal display of the free digital
output signals configured in C0116
l Binary interpretation indicates the bit
states
C0155 STATUS WORD
2
g Bit00
Fail Bit08 R/L Status word 2
Extended decimal status word
l Binary interpretation indicates the bit
states
Bit01 Mmax Bit09 —
Bit02 Imax Bit10 —
Bit03 IMP Bit11 —
Bit04 RDY Bit12 —
Bit05 RSP Bit13 —
Bit06 Trip Bit14 —
Bit07 Init Bit15 —
C0156
s
® Selection list 2 Configuration of the free bits of the status
word
1 STAT.B0 2000 DCTRL−PAR*1−O
2 STAT.B2 5002 MCTRL−IMAX
3 STAT.B3 5003 MCTRL−MMAX
4 STAT.B4 5050 NSET−RFG I=O
5 STAT.B5 10650 CMP1−OUT
6 STAT.B14 505 DCTRL−CW/CCW
7 STAT.B15 500 DCTRL−RDY
C0157 g Display of the freely definable bits of the
status word
1 (C0156/1)
... ...
7 (C0156/7)
C0161 ACT TRIP g All fault messages Trip error message
Current fault message (as in C0168/1)
C0167 RESET
FAILMEM
0 0
1 No reset
Reset Reseterror message
C0167 = 1 deletes the history buffer
C0168 g All fault messages List of faults occurred
1 FAIL NO. ACT Currently active fault
2 FAIL NO. OLD1 Last fault
... ... ...
8 FAIL NO. OLD7 Last but six fault
