Configuration
Code table
8
8.4
l
8.4−11 EDSVS9332S EN 6.0−07/2013
IMPORTANT Possible settings Code
Selection Lenze Designation No.
C0183 DIAGNOSTICS g
Drive diagnostics
l Indicates fault or status information
l If several items of fault or status
information are to be shown, the
information with the smallest number is
displayed
0 OK No fault
101 Initialisation Initialisation phase
102 TRIP/fault TRIP active
103 Emergency stop Emergency stop was carried out
104 IMP message Message active
105 Power OFF Function is not supported
111 BSP C135 operation inhibit
Operation inhibited 112 BSP AIF operation inhibit
113 BSP CAN operation inhibit
121 CINH terminal 28 controller inhibit Controller inhibited via X5/28
122 CINH internal 1 controller inhibit DCTRL−CINH1
123 CINH internal 2 controller inhibit DCTRL−CINH2
124 CINH C135/STOP controller inhibit STOP key at the keypad
125 CINH AIF controller inhibit Controller inhibited via AIF
126 CINH CAN controller inhibit Controller inhibited via system bus
141 Switch−on inhibit Restart protection active
142 IMP inhibit Pulse inhibit High−resistance power outputs
151 QSP terminal ext. quick stop Quick stop via MCTRL−QSP
152 QSP−C135 quick stop Quick stop via STOP key on the keypad
153 QSP−AIF quick stop Quick stop via AIF
154 QSP−CAN quick stop Quick stop via system bus
250 Warning C168 Warning active
C0190 NSET ARIT 0 0
1
2
3
4
5 OUT = C46
C46 + C49
C46 − C49
C46 * C49
C46 / C49
C46/(100 − C49) NSET
Arithmetic block in NSET function block.
Connects main setpoint C0046 and additional
setpoint C0040.
C0195 BRK1 T ACT 99.9 0.0 {0.1 s} 99.9 BRK1
Brake closing time. Engagement time of the
mechanical holding brake.
l After the time under C0195 has elapsed,
the "mechanical brake closed" status is
reached.
C0196 BRK T RELEASE 0.0 0.0 {0.1 s} 60.0 BRK1
Brake opening time. Disengagement time of
the mechanical holding brake (see technical
data of the brake).
l After time has elapsed under C0195, the
status "mechanical brake opened" is
reached.
C0200 S/W ID g Software manufacturer’s product code
Software identification
C0201 S/W DATE g Software generation
Creation date
C0203 COMM. NO. g x / xxxx / xxxxx Commission number
C0204 SERIAL−NO. g 0 {1} 65535 Serial number
