12. Authentication
71 AirLive RS-2500 User’s Manual
12.2 Auth User
 Authentication-User Name
 The user account for Authentication you want to set.
 Password
 The password when setting up Authentication.
 Confirm Password
 Retype the password to confirm it.
 Configuration Example
Configure specific users to connect with external network only when they pass the
authentication of policy.（Adopt the built-in Auth User and Auth Group, RADIUS, or POP3
Function）
STEP 1 ﹒ Setup several Auth User in Authentication. (Figure 12-4)
Figure 12-4 Setting Several Auth Users WebUI
To use Authentication, the DNS Server of the user’s network card
must be the same as the LAN Interface Address of RS-2500.
STEP 2 ﹒ User also can select to authenticate user with RADIUS server. Just need to enter
the Server IP, Port number, password, and enable the function.
 Enable
RADIUS Server Authentication
 Enter RADIUS Server IP
 Enter
RADIUS Server Port
 Enter password in Shared Secret
 Complete the setting of RADIUS Server (Figure 12-5)
Figure 12-5 Setting RADIUS WebUI
