16. VPN
AirLive RS-2500 User’s Manual 102
16.2 IPSec Autokey
 i:
 To display the VPN connection status via icon.
Chart --
Meaning Not be applied Disconnect Connecting
 Name:
 The VPN name to identify the IPSec Autokey definition. The name must be the
only one and cannot be repeated.
 Gateway IP:
 The WAN interface IP address of the remote Gateway.
 IPSec Algorithm:
 To display the Algorithm way.
 Configure:
 Click Modify to change the argument of IPSec; click Remove to remote the
setting. (Figure 16-7).
Figure 16-7 IPSec Autokey WebUI
 Necessary Item (Figure 16-8)
Figure 16-8 Necessary Item WebUI
