AirLive RS-2500 - Manual (Page 61)

9. Service
AirLive RS-2500 User’s Manual 56
STEP 2 ﹒ Enter the following setting in Custom of Service function:
 Click New Entry (Figure 9-3)
 Service Name: Enter the preset name VoIP
 Protocol#1 select TCP, do not change the Client Port, and set the Server
Port as: 1720:1720
 Protocol#2 select TCP, do not change the Client Port, and set the Server
Port as: 15328:15333
 Protocol#3 select UDP, do not change the Client Port, and set the Server
Port as: 15328:15333
 Click OK (Figure 9-4)
Figure 9-3 Add User Define Service
Figure 9-4 Complete the Setting of User Define Service of VoIP
Under general circumstances, the range of port number of client is
0-65535. Change the client range in Custom of is not suggested.
If the port numbers that enter in the two spaces are different port
number, then enable the port number under the range between the
two different port numbers (for example: 15328:15333). And if the port
number that enters in the two spaces is the same port number, then
enable the port number as one (for example: 1720:1720).
