19. Configuration Example: Policy
169 AirLive RS-2500 User’s Manual
19.5 Configuration Example (5) - QoS, Virtual Server, MAX.
Concurrent Sessions
Set a FTP Server under DMZ NAT Mode and restrict the download bandwidth and the MAX.
Concurrent Sessions.
STEP 1 ﹒ Set a FTP Server under DMZ, which IP is 192.168.254.2. (The DMZ Interface
Address is 192.168.254.1/24)
STEP 2 ﹒ Enter the following setting in Virtual Server1 of Virtual Server function:
(Figure 19-23)
Figure 19-23 Setting up Virtual Server Corresponds to FTP Server
When using the function of Incoming or WAN to DMZ in Policy,
strong suggests that cannot select ANY in Service. It may be
attacked by Hacker easily.
STEP 3 ﹒ Enter the following in QoS: (Figure 19-24)
Figure 19-24 QoS Setting
