AirLive RS-2500 - Manual (Page 28)

5. Administration
23 AirLive RS-2500 User’s Manual
5.3 Software Update
STEP 1 ﹒ Select Software Update in System, and follow the steps below:
 To obtain the version number from Version Number and obtain the latest
version from Internet. And save the latest version in the hardware of the PC,
which manage the RS-2500
 Click Browse and choose the latest software version file.
 Click OK and the system will update automatically. (Figure 5-5)
Figure 5-5 Software Update
It takes 4 minutes to update software. The system will reboot after
update. During the updating time, please don’t turn off the PC or close
WebUI. It may cause some unexpected mistakes. (Strong suggests
updating the software from LAN to avoid unexpected mistakes.)
5.4 Logout
STEP 1 ﹒ Click Logout in System to protect the system while admin is away. (Figure 5-6)
Figure 5-6 Confirm Logout WebUI
STEP 2 ﹒ Click OK and the logout message will appear in WebUI. (Figure 5-7)
Figure 5-7 Logout WebUI Message
