11. QoS
67 AirLive RS-2500 User’s Manual
How the Priority function can work?
1. WAN speed is defined 2048/2048 Kbps.
2. QoS_1 rule is defined the Guarantee Bandwidth with 1024/512
Kbps
3. QoS_2 rule is defined the Guarantee Bandwidth with 512/256
Kbps
4. The undefined WAN bandwidth has 512/256 Kbps
5. When G. Bandwidth is not enough, system will assign undefined
bandwidth to support QoS rule
6. QoS rule with high priority can get extra bandwidth first
7. G. Bandwidth + extra bandwidth will not exceed M.
Bandwidth
8. If all QoS rules were set to same level priority, the first user who
needs the extra bandwidth can get the bandwidth
