22. Monitor
AirLive RS-2500 User’s Manual 220
22.5 Wake On Lan
Wake on Lan (WOL) function works to power on the computer remotely. The computer’s
network card must also support WOL function, when it receive the waked up packets and
the computer will auto boot up.
Normally the broadcast packets are not allowed to transfer within Internet, but user can
login RS-2500 remotely and enable Wake on Lan function to boot up the LAN computer.
 Configuration Example - Wake On Lan
STEP 1
﹒
Select Setting in Wake on Lan, and enter MAC Address to specify the computer
who needs to be booted up remotely. User can press Assist to obtain the MAC
Address from the table list. (Figure 22-31)
Figure 22-31 Wake on Lan Setting
STEP 2
﹒
User only needs to press Wake Up button to boot up the specific LAN computer.
(Figure 22-32)
Figure 22-32 Complete Wake on Lan Setting
