6. Configure
37 AirLive RS-2500 User’s Manual
6.7 Host Table
 Host Name
It can be set by System Manager, to allow internal user accessing the information provided
by the host of the domain.
 Virtual IP Address
The virtual IP address is corresponding to the Host. It must be LAN or DMZ IP address.
STEP 1
﹒
Select Host Table in Settings function and click on New Entry
 Host Name: The domain name of the server
 Virtual IP Address: The virtual IP address is corresponding to the Host.
 Click OK to add Host Table. (Figure 6-15)
Figure 6-15 Add New Host Table
To use Host Table, the user PC’s first DNS Server must be the same
as the LAN Port or DMZ Port IP of RS-2500. That is, the default
gateway.
6.8 Language
Select the Language version (English Version/ Traditional Chinese Version or
Simplified Chinese Version) and click OK. (Figure 6-16)
Figure 6-16 Language Setting WebUI
