22. Monitor
AirLive RS-2500 User’s Manual 216
22.4 Diagnostic
The device can trace the route of a packet by Traceroute command to diagnose the quality
of the traversed network, and ensure that a host computer it is trying to reach is actually
operating by ping.
This chapter will be discussing the functionality and application of Diagnostic.
 Ping
STEP 1 ﹒ To test whether a host is reachable across an IP network, navigate to Monitor
Diagnostic  Ping, and then configure as below: (Figure 22-26)
 Type the Destination IP or Domain name in the Destination IP / Domain
name field.
 In Packet size configure the size of each packet. (32 Bytes by default)
 In Count, configure the quantity of packets to send out. (4 by default)
 In Wait time, specify the duration to wait between successive pings.
(1 second by default)
 Select the interface from the Interface drop-down list.
 Click OK.
(Figure 22-27)

Figure 22-26 Ping Settings
