8. Address
49 AirLive RS-2500 User’s Manual
STEP 2 ﹒ Adding the LAN Address setting in Source Address of Outgoing Policy, and only
assign FTP service in the Policy rule. (Figure 8-3)
Figure 8-3 Add a Policy of Restricting the Specific IP to Access to Internet
STEP 3 ﹒ Complete assigning the specific IP to static users in Outgoing Policy and restrict
them to access FTP net service only through policy: (Figure 8-4)
Figure 8-4 Complete the Policy of Restricting the Specific IP to Access to Internet
When the System Administrator creates the Address list, he/she can
choose the way of clicking on to make the RS-2500
to fill out the user’s MAC Address automatically.
The setting mode of WAN and DMZ of Address are the same as
LAN; the only difference is WAN cannot set up MAC Address.
