11. QoS
AirLive RS-2500 User’s Manual 62
11
11.
QoS
By configuring the QoS, you can control the OutBound and InBound
Upstream/Downstream Bandwidth. The administrator can configure the bandwidth
according to the WAN bandwidth.
 Downstream Bandwidth: To configure the Guaranteed Bandwidth and Maximum
Bandwidth.
 Upstream Bandwidth: To configure the Guaranteed Bandwidth and Maximum
Bandwidth.
 QoS Priority: To configure the priority of distributing Upstream/Downstream and
unused bandwidth.
The RS-2500 configures the bandwidth by different QoS, and selects the suitable QoS
through Policy to control and efficiently distribute bandwidth. The RS-2500 also makes it
convenient for the administrator to make the Bandwidth to reach the best utility.
(Figure 11-1, 11-2)
Figure 11-1 the Flow Before Using QoS
