AirLive RS-2500 - Manual (Page 161)

19. Configuration Example: Policy
AirLive RS-2500 User’s Manual 156
19
19.
Configuration Example:
Policy Setting
19.1 Configuration Example (1) - Traffic Log, Statistic
Set up the policy that can monitor the internal users. (Take Traffic Log and Statistics for
example)
STEP 1 ﹒ Enter the following setting in Outgoing Policy:
 Click New Entry
 Select Traffic Log
 Select Statistics
 Click OK (Figure 19-1)
Figure 19-1 Setting the different Policies
STEP 2 ﹒ Complete the setting of Logging, Statistics, and Alarm Threshold in Outgoing
Policy: (Figure 19-2)
Figure 19-2 Complete Policy Setting
