22. Monitor
221 AirLive RS-2500 User’s Manual
22.6 Status
The users can know the connection status in Status. For example: LAN IP, WAN IP, Subnet
Netmask, Default Gateway, DNS Server Connection,
and its IP…etc.
 Interface: Display all of the current Interface status of the RS-2500
 Authentication: The Authentication information of RS-2500
 ARP Table: Record all the ARP that connect to the RS-2500
clients that are connected to the RS-2500.
STEP 1 the setting for each Interface:
(Figure 22-33)
 Forwarding Mode: The connection mode of the Interface
 WAN Connection: To display the connection status of WAN
 Max. Downstream / Upstream Kbps: To display the Maximum
Downstream/Upstream Bandwidth of that WAN (set from Interface)
 Downstream All tage of Downstream according
to WAN traffic
ffic
 PPPoE Con. Time: The last time of the RS-2500 to be enabled
 MAC Address: The MAC Address of the Interface
 IP Address/ tmask of the Interface
 Default Gateway: To display the Gateway of WAN
 DNS1/2: The DNS1/2 Server Address provided by ISP
 Rx/Tx Pkts, Error Pkts: To display the received/sending packets and error
packets of the Interface
 Ping, HTTP: To display whether the users can Ping to the RS-2500 from the
Interface or not; or enter its WebUI
 DHCP Clients: Display the table of DHCP
 Status - Interface
﹒ Enter Interface in Status function; it will list
oca.: The distribution percen
 Upstream Alloca.: The distribution percentage of Upstream according to
WAN tra
Netmask: The IP Address and its Ne
