5. Administration
AirLive RS-2500 User’s Manual 22
5.2 Permitted IP
 Add Permitted IPs
STEP 1 ﹒ Add the following setting in Permitted IPs of Administration: (Figure 5-3)
 Name: Enter master
 IP Address: Enter 163.173.56.11
 Netmask: Enter 255.255.255.255
 Service: Select Ping, HTTP and HTTPS
 Click OK
 Complete add new permitted IPs (Figure 5-4)
Figure 5-3 Setting Permitted IPs WebUI
Figure 5-4 Complete Add New Permitted IPs
To make Permitted IPs be effective, it is suggested to cancel the Ping,
HTTP, and HTTPS selection in LAN, WAN, or DMZ Interface setting.
Before canceling the WebUI selection of Interface, user must set up
the Permitted IPs first, otherwise, it would cause the situation that
user cannot enter WebUI by appointed Interface.
