18. Policy

AirLive RS-2500 User’s Manual

152

18.

Policy

Every packet has to be detected if it corresponds with Policy or not when it passes the

RS-2500. When the conditions correspond with certain policy, it will pass the RS-2500 by

the setting of Policy without being detected by other policy. But if the packet cannot

correspond with any Policy, the packet will be intercepted.

The parameter of the policy includes Source Address, Destination Address, Service,

Schedule, Authentication User, Trunk, Action-WAN Port, Traffic Log, Statistics, Content

Blocking, Application Blocking, QoS, MAX. Bandwidth Per Source IP, MAX. Concurrent

Sessions Per IP, and MAX. Concurrent Sessions. Control policies decide whether packets

from different network objects, network services, and applications are able to pass through

the RS-2500.

How to use Policy?

The device uses policies to filter packets. The policy settings are: source address,

destination address, services, permission, packet log, packet statistics, and flow control.

Based on its source addresses, a packet can be categorized into:

(1) Outgoing: The source IP is in LAN network; the destination is in WAN network.

The system manager can set all the policy rules of Outgoing packets in this function

(2) Incoming: The source IP is in WAN network; the destination is in LAN network.

(For example: Mapped IP, Virtual Server) The system manager can set all the

policy rules of Incoming packets in this function

(3) WAN to DMZ: The source IP is in WAN network; the destination is in DMZ network.

(For example: Mapped IP, Virtual Server) The system manager can set all the

policy rules of WAN to DMZ packets in this function

(4) LAN to DMZ: The source IP is in LAN network; the destination is in DMZ network.

The system manager can set all the policy rules of LAN to DMZ packets in this

function

(5) DMZ to LAN: The source IP is in DMZ network; the destination is in LAN network.

The system manager can set all the policy rules of DMZ to LAN packets in this

function
