6. Configure

AirLive RS-2500 User’s Manual

 NAT Mode

It allows Internal Network to set multiple subnet address and connect with the Internet

through different WAN IP Addresses.

For example, the lease line of a company applies several real IP Addresses 168.85.88.0/24,

and the company is divided into Service, Sales, Procurement, and Accounting

department, the company can distinguish each department by different subnet for the
purpose of managing conveniently. The settings are as the following：

1. R&D department subnet：192.168.1.1/24 (LAN)

 168.85.88.253 (WAN)

2. Service department subnet：192.168.2.1/24 (LAN)

 168.85.88.252 (WAN)

3. Sales department subnet：192.168.3.1/24 (LAN)

 168.85.88.251 (WAN)

4. Procurement department subnet：192.168.4.1/24 (LAN)

 168.85.88.250 (WAN)

5. Accounting department subnet：192.168.5.1/24 (LAN)

 168.85.88.249 (WAN)

The first department (R&D department) had set while setting interface IP; the other four

ones have to be added in Multiple Subnet. After completing the settings, each department

uses the different WAN IP Address to connect to the Internet. The settings of each

department are as following:

Service Sales

Procurement

Accounting

IP Address

192.168.2.2~254 192.168.3.2~254 192.168.4.2~254 192.168.5.2~254

Subnet

Netmask

255.255.255.0 255.255.255.0 255.255.255.0 255.255.255.0

Gateway 192.168.2.1

192.168.3.1 192.168.4.1 192.168.5.1

 Routing Mode

It is the same as NAT mode approximately but does not have to correspond to the real

WAN IP address, which let internal PC to access to Internet by its own IP. (External user

also can use the IP to connect with the Internet)
