7. Interface
43 AirLive RS-2500 User’s Manual
Figure 7-6 Complete PPPoE Connection Setting
 Dynamic IP Address (Cable Modem User) (Figure 7-7):
1. Select Dynamic IP Address (Cable Modem User)
2. Click Renew in the right side of IP Address and then can obtain IP
automatically.
3. If the MAC Address is required for ISP then click on Clone MAC Address to
obtain MAC IP automatically.
4. Hostname: Enter the hostname provided by ISP.
5. Domain Name: Enter the domain name provided by ISP.
6. User Name and Password are the IP distribution method according to
Authentication way of DHCP + protocol
7. Enter Max. Downstream Bandwidth and Max. Upstream Bandwidth
(According to the flow applied by user)
8. Select Ping, HTTP and HTTPS, and click OK (Figure 7-8)
Figure 7-7 Dynamic IP Address Connection
