17. Configuration Example: IPSec & PPTP VPN
135 AirLive RS-2500 User’s Manual
Figure 17-77 Enable PPTP VPN Server Settings
Client IP Range: the setting can not be the same as LAN IP subnet,
or the PPTP function will not be workable.
Idle Time: the setting time that the VPN Connection will
auto-disconnect under unused situation. (Unit: minute)
STEP 2. Add the following settings in PPTP Server of VPN function in the RS-2500 of
Company A:
 Select
New Entry. (Figure 17-78)
 User Name: Enter jacky.
 Password: Enter 123456789.
 Client IP assigned by: Select IP Range.
 Click
OK. (Figure 17-79)
Figure 17-78 PPTP VPN Server Setting
