Chapter 2
Inside/back of main unit
*The illustration above shows the main unit with the optional original cover
and ADF installed.
No. Part name Description
1 Document pad Presses down on the document positioned on
the original glass
2 Original glass Scans the image of the loaded document (See
page 3-10)
3 Switchback unit Built into the printer to turn over the paper dur-
ing double-sided printing
4 Automatic duplex unit Turns over the paper for double-sided printing
5 Right-side door Open when clearing paper misfeeds in the right-
side door unit or the fusing unit
6 Toner hopper Used when installing and replacing the toner
bottles
7 Document scales Used to align the document (See page 3-10)
8 Power cord Supplies power to the machine
TEL PORT 1
LINE PORT 1
TEL PORT 2
LINE PORT 2
11
9
8
10
12
13
14
15
16 17
1
2
7
6
3
4 5
