Chapter 7. Module Terminal Menus
61200305L1-1 ATLAS 550 User Manual 7-3
ule to be marked O FFLINE , which may be useful in system troubleshooting.
If you choose O FFLINE , the module will not be in alarm condition, but will
display O FFLINE .
S TATUS Read security: 5
Displays status information on the ATLAS 550 ports and other installed
modules as follows:
R EV Read security: 5
Displays the hardware revision of the ATLAS 550 and other installed mod-
ules.
Modules Menu (T1Network Interface Module)
This section provides detailed information on the M ODULES / M ENU sub-
menus. M ENU provides access to commands that allow you to review the sta-
tus of various options, change the configuration for general parameters, and
initiate tests. This section only describes the menu options for the T1 Net-
work Interface Module. For details on menu options for other modules, refer
to the appropriate module manuals.
To configure the T1 Network Interface Module in the Dial Plan, use the de-
scriptions provided for the Dual T1/PRI Module (see page 11-10).
Once a module is installed, S TATE must be set to O NLINE for the
ATLAS 550 to use the module for any data bandwidth. O NLINE
is the default setting.
O NLINE The module is enabled and is responding to the system
controller’s status polls. This is the normal response of the
system.
N O R ESPONSE The module is enabled but is not responding to the
system controller’s status polls. This response indicates a
problem in the system or that the module is not installed.
E MPTY The system controller has not detected the presence of a
module in the system, nor has a module been manually
enabled for this option slot.
O FFLINE The module is installed but has been taken offline by a
user. The module is still responding to controller polls.
O FFLINE /N O
R ESPONSE
The module is installed but has been taken offline by a
user. The module is not responding to polls.
N OT
S UPPORTED
The module is not supported by the current system
configuration.
