Chapter 9. Router
61200305L1-1 ATLAS 550 User Manual 9-5
U SED Read Security: 5
Displays the number of times the router has referenced this route.
C LR Write security: 2; Read security: 5
Clears the
U SED count field for this route.
F LAGS Read security: 5
Indicates the properties of this routing table entry, composed of the follow-
ing letters:
H OPS Read security: 5
Displays the number of router hops required to get to the network or host.
Ranges from 0 to 16. If set to 16, it is defined as infinite and cannot be
routed.
TTL Read security: 5
Displays the number of seconds until the address is removed from table.
Value of 999 means the route is static.
I NTERFACES The I NTERFACES M ENU configures and monitors all interfaces connected to
the ATLAS 550 router. These include the Ethernet and frame relay DLCIs
connected in the
P ACKET M ANAGER / P ACKET C NCTS .
N ETWORK N AME Read security: 5
Displays the name of the interface connected to the ATLAS 550 router. The
options are listed below:
EN0 IP The ATLAS 550 Ethernet port.
E NDPOINT N AME The DLCI number.
A DDRESS Write security: 2; Read security: 5
Defines the individual interface IP address. If this field is left as 0.0.0.0, it is
treated as an unnumbered interface.
H - route is a host route
G - route is a gateway route
D - route learned dynamically from RIP
I - route learned from an ICMP redirect
P - route is private and is not advertised with RIP
T - route is to a triggered port (updated only when table changes)
