Chapter 5. Navigating the Terminal Menus
61200305L1-1 ATLAS 550 User Manual 5-3
Right Window Pane Notation
The right window pane shows the contents of the currently selected menu.
These contents can include both submenu items and data fields. Some sub-
menus contain additional submenus and some data fields contain additional
data fields. The following chart explains the notation used to identify these
additional items.
Additional Terminal Menu Window Features
The following features are located across the bottom of the window:
Sys
Describes the status of the ATLAS 550 base unit.
Tool Tip
Provides a brief description of the currently selected (highlighted) field.
Slot Status
Displays status information, such as OK, WARN (warning), or ALRM
(alarm), about slots 1 through 4.
To move... Press one of these keys...
From left pane to right pane Tab
Enter
Left arrow
Right arrow
From right pane to left pane Tab
Escape
Left arrow
Right arrow
Within each pane Up arrow
Down arrow
Left arrow
Right arrow
This notation... Means that...
[+] More items are available when selected.
[DATA] More items are available when selected.
<+> An action is to be taken, such as activating a test.
Highlighted menu item You can enter data in this field.
Underlined field The field contains read-only information.
