Chapter 14. ADTRAN Utilities

14-2

ATLAS 550 User Manual

61200305L1-1

SysLog GUI

Figure 14-1 shows the SysLog Host GUI. The conventional Menu Bar is de-
scribed beginning on page 14-3 (see also Figure 14-2 on page 14-3). Other
features are described here.

Figure 14-1. ATLAS 550 SysLog Host GUI

Monitor

The

M

ONITOR

feature allows all SysLog messages to be pre-filtered by

S

YS

-

TEM

N

AME

, S

OURCE

, S

LOT

and

P

ORT

before displaying these messages to the

user and logging the message to the pre-designated monitor log file.

System Name

Select from pull-down menu.

Source

Provides var-
ious filter op-
tions for the
ATLAS 550.

Slot

Select applicable slots (0—4).

Port

Select applicable port range.
