Chapter 14. ADTRAN Utilities
14-8 ATLAS 550 User Manual 61200305L1-1
H ELP Provides on-line help for using the ADTRAN Utilities.
C ONTENTS Opens the on-line help.
IP S TATUS Displays the local port address and the status of the connection.
A BOUT Displays version and owner information.
VT-100 UTILITY
Use the VT-100 to configure an ATLAS 550 which is directly connected to a
PC. The VT-100 display is almost identical to the Telnet display. If you need
help setting up the ATLAS 550 for a VT-100 session, refer to Using VT-100
Terminal Emulation on page 3-1. VT-100 menus include
S ESSION , E DIT , P ORT ,
O PTIONS , C APTURE , and H ELP (see the menu tree in Figure 14-4).
Figure 14-4. VT-100 Menu Tree
Connect
Session Disconnect
File Transfer XMODEM CRC
Exit ASCII Cfg Files Send Cfg File
Edit Copy
Paste
Port Settings
Refresh Screen Transmit Wakeup
Connect Transmit Refresh
VT-100 Options Colors
Local Echo BackGround
Auto Repeat Bold
Text
File Start Cfg Capture
Capture Buffer Size Stop Cfg Capture
Save Buffer As
Screen Capture
Help Contents
About
