Appendix C. Frame Relay Examples
C-6 ATLAS 550 User Manual 61200305L1-1
Step 3 From P ACKET M ANAGER /P ACKET C NCTS , connect the packet endpoints (see
Figure C-16).
Figure C-16. Menu for Connecting Packet Endpoints
Step 4 Connect the packet endpoint to the physical interface (see Figure C-17).
Figure C-17. Menu for Connecting Packet Endpoint to Physical Interface
Example 4: Public Frame Relay Network—IP Data and Packet
Voice
Example 4 (see Figure C-18 on page C-7) depicts a public frame relay
network with IP data and packet voice. An ATLAS 550 is located at the
central site, and an Express 5210 is located at each remote site. ATLAS 550
acts as the central-site router and performs voice switching. To re-create this
example, follow the process discussed below.
Packet voice termination requires the V OICE C OMPRESSION
M ODULE .
