Chapter 9. Router
61200305L1-1 ATLAS 550 User Manual 9-3
IP MENUS
The IP M ENU defines and monitors IP routes (see Figure 9-2).
Figure 9-2. IP Routes Menu
S TATIC R OUTES The S TATIC R OUTES M ENU manages static IP routes. You can create, modify,
and delete routes using this menu.
IP A DDRESS Write security: 2; Read security: 5
Defines the IP address of the host or network device being routed to.
N ETMASK Write security: 2; Read security: 5
Determines for routing the number of bits used in the above-defined IP
address. If a host address is desired for the IP address, this field must be set
to 255.255.255.255.
G ATEWAY Write security: 2; Read security: 5
Defines the IP address of the router to receive the forwarded IP packet.
I NTERFACE Write security: 2; Read security: 5
Defines the interface to which IP packets with this address will be routed.
These are either Ethernet or frame relay DLCIs.
H OPS Write security: 2; Read security: 5
Defines the number of router hops required to get to the network or host.
Maximum distance is 15 hops.
E NABLED Write security: 2; Read security: 5
Enables or disables this static route.
A DVERTISE Write security: 2; Read security: 5
When set to
Y ES , this static route is advertised over all interfaces on which a
route advertisement protocol (e.g. RIP) is enabled. When set to N O , this is a
private route.
